Model 6040-709 Electric Tilt Table

quick ship weight capacity
  • Heavy duty electrical tilt mechanism.
  • Pneumatic hand control operable from either side of table.
  • Fixed table height is 33" high.
  • Removable padded footboard.
  • Tilts from horizontal to 90° at fixed rate of speed of 3° per second.
  • Limit switches. Hospital grade plug. 110V, 60Hz, 3 amps.
  • Gray vinyl upholstery.
  • 2" High-density urethane foam top.
  • Tilt angle indicator from 0° to 90°.
  • Three extra-wide safety straps.
  • Set of (4) 4" locking casters.
  • Heavy duty steel frame is powder coated in neutral cream finish. 3 ½" clearance under frame.
  • Designed for rehab and therapy.
  • Not designed for cardiac testing.
  • English
  • Metric

Weight Capacity: 300 lbs.

MODEL #
LENGTH
WIDTH
HEIGHT
6040-709
78"
28"
33"

Weight Capacity: 136 kg

MODEL #
LENGTH
WIDTH
HEIGHT
6040-709
198 cm
71 cm
84 cm

6040-709
Options:
  • 6026 – Additional Safety Strap
  • 077* – (4) 6" Casters (increases height and clearance by 2").

*Factory Installed.
